40a No Nc Modular Contactor

China Manufacturers ICHYTI Advanced 40a no nc modular contactor Price is an electrical control component with high production capacity and wide application range, which can be widely used for frequent switching of AC or DC main circuits as well as large capacity control circuits. Contactors and relays can be used to achieve functions such as timed operation, interlocking control, quantitative control, pressure application, and undervoltage protection.

ICHYTI 40a no nc modular contactor Parameter (Specification)

Product model	Pole	Usage category	Insulation voltage	Working voltage	Fever current	Working current	Control circuit voltage	Control power
KCH8-2520	2P	AC-1 AC-7a AC-7b	500V	250V	25A	25/9A	220V	5.4/1.5
KCH8-2502
KCH8-2511
KCH8-6320			500V	250V	63A	63/20A	220V	12/3.8
KCH8-6302
KCH8-6311
KCH8-2540	4P		500V	400V	25A	25/9A	24V/ 220V	16/3
KCH8-2504
KCH8-2522
KCH8-6340			500V	400V	63A	63/20A	220V	40/6.5
KCH8-6304
KCH8-6322



ICHYTI 40a no nc modular contactor Our services

◉ There are multiple models of industrial automation products to choose from. If you cannot find the desired model, please leave us a message and we will do our best to meet your needs.
◉ If you need to know the detailed parameters of the product to determine if it is suitable for your needs, please leave us a message and we will provide available data for your reference as soon as possible.
◉ The price provided for this product refers to the list price of a brand new genuine product. If you think the price is high, you can consult our second-hand products. Although these products have some usage marks, their appearance and function are still good.
◉ In short, regardless of your questions and needs, we welcome your consultation. Please understand that we may not be able to reply to your message immediately during non working hours.

ICHYTI 40a no nc modular contactor Details

ICHYTI 40a no nc modular contactor Dimensions



ICHYTI 40a no nc modular contactor FAQ

Q: How is the situation regarding delivery? Because I really need these products urgently.
A: We usually have sample inventory available for supply. For bulk orders, a delivery time of 7 days is usually required.

Q: When should I replace the AC contactor?

A: Most manufacturers recommend replacing the silver pads on AC contacts and some DC contacts with silver tips when they are half worn. Electrical contacts typically withstand frequent arc usage, even with small jumps. Even the largest size contacts will wear out after prolonged use.
