3 Pin 15 AMP AC Power Socket with Fuse

ICHYTI is a leading manufacturer of 20 amp ac fuse in China, with excellent product quality and very reasonable prices. We welcome customers to contact us. In addition to providing OEM and ODM services, we also support customers in selling our brand to overseas markets and provide more competitive sales policies.

Send Inquiry PDF DownLoad

Product Description

Each individual member from our large performance revenue crew values customers' requirements and organization communication for 3 Pin 15 AMP AC Power Socket with Fuse, Trust us and you will gain a lot more. You should truly feel totally free to make contact with us for additional data, we assure you of our greatest notice at all times. 3 Pin 15 AMP AC Power Socket with Fuse, AC Power Socket Types, AC Power Socket with Fuse and Switch, Our goods are produced with the best raw materials. Every moment, we constantly improve the production programme. In order to ensure better quality and service, we have been focusing on the production process. We have now got high praise by partner. We're looking forward to establishing business relationship with you.

China Factory ICHYTI Low Price 3 Pin 15 AMP AC Power Socket with Fuse Made in China is to detect and cut off excessive current in the circuit, using an 18 wire heating automatic triggering protection mechanism to protect the circuit from damage. 3 Pin 15 AMP AC Power Socket with Fuse is suitable for various fields such as electronic products, communication products, and power supplies.

ICHYTI 3 Pin 15 AMP AC Power Socket with Fuse Parameter (Specification)

Product Model	RT18-32X
Pole	1P
Colour	White/blue
Rated Current (A)	2,4, 6, 8, 10, 12, 16, 20, 25, 32
Rated Voltage(V)	500
Breaking capacity(kA)	50
Installation	Rail installation
Fuse link size(mm2)	10*38

ICHYTI 3 Pin 15 AMP AC Power Socket with Fuse Feature

The body of the variable cross-section fuse is made of pure copper sheet (or copper wire, silver wire, silver sheet), and is encapsulated in a fuse tube made of high-strength porcelain or epoxy glass cloth tube. The fused tube is filled with chemically treated high-purity quartz sand, which is used to extinguish the arc medium in the tube. The two sides of the fuse are reliably connected by spot welding and end plates, forming a cylindrical cap like structure. The fuse base is pressed by a resin or plastic casing containing contacts and includes a fuse element, which is riveted and connected as a support for appropriately sized fuse body parts.

ICHYTI 3 Pin 15 AMP AC Power Socket with Fuse Details

ICHYTI 3 Pin 15 AMP AC Power Socket with Fuse Dimensions and wiring

ICHYTI 3 Pin 15 AMP AC Power Socket with Fuse Common types

A fast fuse is an electronic component specifically used for short-circuit protection of semiconductor rectifier components or rectifier devices. Due to the low overload capacity of semiconductor components, they can only withstand overload currents for an extremely short period of time, so it is necessary for fast fuses to have the ability to quickly fuse.

The structure of a fast fuse is basically the same as that of a sealed fuse with filler, but the melt material and shape are different. It is a variable cross-section melt with V-shaped deep grooves stamped with silver plates. Quick fuses, commonly referred to as "fast fuses", are characterized by fast fusing speed, high rated current, strong breaking capacity, stable current limiting characteristics, and small size.

Hot Tags: AC Power Socket with Fuse, AC Power Socket Types, AC Power Socket with Fuse and Switch
